AMF THERMATEX® Alpha HD 19mm
- Excellent sound absorption (0.95 αw and 0.85 NRC)
- Good sound attenuation (34 dB)
- Excellent light reflectance (88%)
- Excellent fire reaction (A2-s1, d0)
Applications
AMF THERMATEX® Alpha HD 19mmSmooth laminated mineral ceiling tile, excellent sound absorption and good attenuation
Description & Details
AMF THERMATEX® Alpha HD 19mm is a mineral acoustic ceiling tile in 19 mm and available in five edge details. With its smooth laminated surface, it offers excellent sound absorption and good sound attenuation. It has an excellent light reflectance and thanks to its exceptional air permeability (no filter effect), the surface remains whiter and brighter for an extended duration. This makes AMF THERMATEX® Alpha HD 19mm an ideal choice for offices, classrooms, learning applications and corridors. AMF THERMATEX® Alpha HD 19mm is Cradle to Cradle Certified® Bronze, accredited Eurofins Indoor Air Comfort® GOLD and has an Environmental Product Declaration (EPD).
- Excellent sound absorption (0.95 αw and 0.85 NRC)
- Good sound attenuation (34 dB)
- Excellent light reflectance (88%)
- Excellent fire reaction (A2-s1, d0)
- Exceptional air permeability (PM1 (≤ 30 m³/hm²))
- Ideal for offices, classrooms, learning applications and corridors
- Industrial building
- Office building
- Leisure & Hospitality
Documents
Certificates
Product Variants & Packaging
AMF THERMATEX® Alpha HD 19mm
| Material number | EAN / GTIN | Edge detail | Length | Width | Thickness | Colour | Sound absorption coefficient | Sound absorption class | Sound absorption (NRC) | Sound attenuation DNFW (DB) | Sound attenuation CAC (DB) |
|---|---|---|---|---|---|---|---|---|---|---|---|
00728111 | 4044617252595 | Board | 1,200 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00733331 | 4044617257187 | Board | 600 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00719862 | 4044617248611 | Finesse | 1,200 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00713573 | 4044617244620 | Finesse | 600 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00729654 | 4044617254438 | SL2 | 1,500 mm | 300 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00713574 | 4044617244637 | SL2 | 1,800 mm | 300 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00748741 | 4044617265632 | Tegular 15/90 | 1,200 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00724143 | 4044617250386 | Tegular 15/90 | 600 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00811489 | 4044617308902 | Tegular 24/90 | 1,200 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
00811488 | 4044617308896 | Tegular 24/90 | 600 mm | 600 mm | 19 mm | white | 0.90 | A | 0.85 | 34 | 35 |
